MOTOR SETTINGS REFERENCE
Optimized Motor Settings for Root Canal Instruments
Use this reference as a general clinical guideline for Endodontist Pro Series instruments. Always follow the manufacturer's instructions for use and apply your clinical judgment based on the motor, technique, and clinical situation.
IMPORTANT
These are recommended starting points for EPS instruments. Adjust based on your motor, technique, and clinical situation.
Download Full Reference Guide
Complete motor settings in one PDF
EPS Motor Settings
Reference settings for EPS endodontic instruments.
| Product | Procedure | Size / Series | Speed (RPM) | Torque (N·cm) | Motion |
|---|---|---|---|---|---|
|
Pro Series Shaper — Gold
|
Rotary Shaping | SX – F5 | — | — | Continuous Rotation |
|
Pro Series Shaper — Blue
|
Rotary Shaping | SX – F5 | — | — | Continuous Rotation |
|
Pro Series Shaper — Blue Flex
|
Rotary Shaping | 15 – 40 | — | — | Continuous Rotation |
|
Pro Series Progressive
|
Rotary Shaping | X1 – X5 | — | — | Continuous Rotation |
|
Pro Series Solo — Gold
|
Reciprocating | 20 – 45 | — | — | Reciprocating |
|
Pro Series Glide — Silver
|
Glide Path | 16/.02 | — | — | Continuous Rotation |
|
Pro Series Glide — Gold
|
Glide Path / Reciprocating | 15/.02 | — | — | Reciprocating |
|
Pro Series Retreatment
|
Retreatment | D1 – D3 | — | — | Continuous Rotation |
|
Pro Series C-Plus
|
Hand Negotiation | 06 – 20 | — | — | Hand Use |
|
Pro Series Patency
|
Hand Dredging | 08 – 15 | — | — | Hand Use |
| PRODUCT | PROCEDURE | SIZE / SERIES | SPEED (RPM) | TORQUE (N·CM) | MOTION |
|---|---|---|---|---|---|
| 🟡 Root Canal Shaper — Gold | Rotary Shaping | SX – F5 | 300 – 500 | 1.0 – 3.0 | Continuous Rotation |
| 🔵 Root Canal Shaper — Blue | Rotary Shaping | SX – F5 | 300 – 500 | 1.0 – 3.0 | Continuous Rotation |
| 🔵 Root Canal Shaper — Blue Flex | Rotary Shaping | 15 – 40 | 300 – 500 | 1.0 – 3.0 | Continuous Rotation |
| 🟣 Root Canal Progressive | Rotary Shaping | X1 – X5 | 300 – 500 | 1.0 – 3.0 | Continuous Rotation |
| 🟡 Root Series Solo — Gold | Reciprocating | 20 – 45 | 300 | 1.0 – 2.5 | Reciprocating |
| ⚪ Root Series Glide — Silver | Glide Path | 16/.02 | 300 – 500 | 1.0 – 3.0 | Continuous Rotation |
| 🟡 Root Series Glide — Gold | Glide Path / Reciprocating | 15/.02 | 300 | 1.0 – 2.5 | Reciprocating |
| 🔴 Root Series Retreatment | Retreatment | D1 – D3 | 300 | 1.0 – 3.0 | Continuous Rotation |
| 🟢 Root Series C-Plus | Hand Negotiation | 06 – 20 | 300 | 1.0 – 2.0 | Hand Use |
| ⚪ Root Series Patency | Hand Dredging | 08 – 15 | 300 | 1.0 – 2.0 | Hand Use |
